CNC Turret Punch Press
TIHST1250
The Tommy Industrial Hydraulic CNC Turret punch machine incorporates German engineered SIEMENS numerical control systems and Ac servo motor for three axis drive. This machine process plate along the x and y axis. The Tommy Industrial Turret Punch Press can punch holes, round, square and custom shapes. This machine can be programmed with multiple programs allowing operators to select project modes with ease.
The Tommy Industrial Hydraulic CNC Turret Punch Machine is built on a heavy duty fully welded frame allowing for 100% stability. The Punching table of the machine utilizes the standard roller ball system allowing material to easly glide when being processed.
All Tommy Industrial Hydraulic CNC Turret Punch Machines are fully customizable and built to order. For more information, contact a Tommy Industrial sales representative today! Check out the speciation’s:
| Item | Imperial | Metric | |
|---|---|---|---|
| Nominal force | 30 ton | 300 KN | |
| Workpiece size | 49x98 in | 1250x2500 mm | |
| Max. workpiece thickness | 0.24 in | 6 mm | |
| Max. punch diameter | Φ3.5 in | Φ88.9 mm | |
| Max. hit speed | 600 h.p.m | 600 h.p.m | |
| Max. stroke | 1.6 in | 40 mm | |
| X/Y axis traveling speed | 262 ft/min | 80 m/min | |
| Workpiece traveling speed | 262 ft/min | 80 m/min | |
| Turret speed | 30 r/min | 30 r/min | |
| Main power | 20 hp | 15 kW | |
| Working accuracy | ±0.004 in | ±0.10 mm | |
| Total station | 24 set | 24 set | |
| Axes | 4 (X, Y, Z,C) | 4 (X, Y, Z,C) | |
| Machine dimensions (length x width x height) | 197x118x83 in | 5000x3000x2100 mm | |
| Machine weight | 26455 lbs | 12000 kg | |
| CNC control system | SIEMENS 808D | SIEMENS 808D | |
| Ball screws | HIWIN, Taiwan | HIWIN, Taiwan | |
| Linear guideways | HIWIN, Taiwan | HIWIN, Taiwan | |
| Servo unit and motor | SIEMENS | SIEMENS | |
| Hydraulic system | Rexroth, Germany | Rexroth, Germany | |
| Valves | Rexroth, Germany | Rexroth, Germany | |
| Pneumatic cylinder | AIRTEC | AIRTEC | |
| Proximity switch | P+F, Germany | P+F, Germany | |
| Automatic programming | JakSOFT | JakSOFT | |
| Mould | Local Company(OPTIONAL ) | Local Company(OPTIONAL ) | |
| Size of each dies | A (qty, 12 sets) | Φ0.10-Φ0.5 in | Φ2.5-Φ12.7 mm |
| B (qty, 8 sets) | Φ0.5-Φ1.25 in | Φ12.7-Φ31.7 mm | |
| C (qty, 2 sets) | Φ1.25-Φ2 in | Φ31.7-Φ50.8 mm | |
| D (qty, 2 sets) | Φ2-Φ3.5 in | Φ50.8-Φ88.9 mm | |
