79" x 25" OVER BED Flat Bed CNC Lathe

TICK6163

With the Tommy Industrial Flat Bed CNC Lathe Series you get affordable reliability and features not usually found on basic Flat Bed CNC Lathes. That's why these CNC Lathes are a favorite for manufactures, fabricators, maintenance shops and machine shops.  Features Include



–Featured with flat bed, wide hard guide way and fulled enclosed safe guard

–Integral bed feet and super sonic hardened guide way

–2 kinds of spindle box equipment for choice

–There are adjusting row tools for choice

Three-jaw chuck

Center and center sleeve

Wrenches

Oil gun

Operation manual

Model TICK6163 Specifications
Item Imperial Metric
Working Area Workpiece length (max.) 59 in/ 79 in 1500 mm/ 2000 mm
Turning length (max.) 53 in/ 73 in 1350 mm/ 1850 mm
Turning diameter over bed 25 in 630 mm
Turning diameter over support 14 in 350 mm
Travels Travel X-axis 19 in 480 mm
Travel Z-axis 59 in/ 79 in 1500 mm/ 2000 mm
Headstock Spindle speed (single) 10-1000 r/min (single) 10-1000 r/min
Spindle mount A2-11 A2-11
Spindle bore 4 in 105 mm
Rapid Feed Rapid feed X-axis 236 in/min 6000 mm/min
Rapid feed Z-axis 315 in/min 8000 mm/min
Tool head Number of tool stations 4 positions 4 positions
Tailstock Tailstock taper MT 6 MT 6
Tailstock quill diameter 6 in 150 mm
Tailstock quill stroke 6 in 150 mm
Drive Capacity Motor rating main drive 29.5 Hp 22 kW
Measures and weights Overall dimensions (length x width x height) 105x91 in 3800x2300 mm
169x91 in 4300x2300 mm
Weight 17637 lbs/ 19842 lbs 8000 kg/ 9000 kg

Request a quote on this product by filling out your contact information and any notes. A sales engineer will respond as soon as possible.
