79" X 31" OVER BED Flat Bed CNC Lathe
TICK6180
This product is not purchasable online at this time. Please call us at 844-895-3316 for purchasing information.
With the Tommy Industrial Flat Bed CNC Lathe Series you get affordable reliability and features not usually found on basic Flat Bed CNC Lathes. That's why these CNC Lathes are a favorite for manufactures, fabricators, maintenance shops and machine shops. Features Include
–Featured with flat bed, wide hard guide way and fulled enclosed safe guard
–Integral bed feet and super sonic hardened guide way
–2 kinds of spindle box equipment for choice
–There are adjusting row tools for choice
Three-jaw chuck
Center and center sleeve
Wrenches
Oil gun
Operation manual| Item | Imperial | Metric | |
|---|---|---|---|
| Working Area | Workpiece length (max.) | 59 in/ 79 in | 1500 mm/ 2000 mm |
| Turning length (max.) | 53 in/ 73 in | 1350 mm/ 1850 mm | |
| Turning diameter over bed | 31 in | 800 mm | |
| Turning diameter over support | 21 in | 530 mm | |
| Travels | Travel X-axis | 19 in | 480 mm |
| Travel Z-axis | 59 in/ 79 in | 1500 mm/ 2000 mm | |
| Headstock | Spindle speed | (single) 10-1000 r/min | (single) 10-1000 r/min |
| Spindle mount | A2-11 | A2-11 | |
| Spindle bore | 4 in | 105 mm | |
| Rapid Feed | Rapid feed X-axis | 236 in/min | 6000 mm/min |
| Rapid feed Z-axis | 315 in/min | 8000 mm/min | |
| Tool head | Number of tool stations | 4 positions | 4 positions |
| Tailstock | Tailstock taper | MT 6 | MT 6 |
| Tailstock quill diameter | 6 in | 150 mm | |
| Tailstock quill stroke | 6 in | 150 mm | |
| Drive Capacity | Motor rating main drive | 29.5 Hp | 22 kW |
| Measures and weights | Overall dimensions (length x width x height) | 150x91 in | 3800x2300 mm |
| 169x91 in | 4300x2300 mm | ||
| Weight | 17637 lbs/ 19842 lbs | 8000 kg/ 9000 kg | |
